The GYXTC8Y Fig 8 Aerial Fiber Optical Cable are positioned in loose tubes that are made of high-modulus plastic and filled with tube gel.
The tubes (and fillers) are stranded around a metallic central strength member to form a cable core.
The core is filled with water-blocking compound and armored with corrugated steel tape(CST).
Stranded steel wires are applied as the messenger.
Finally, a figure-8 PE outer jacket is extruded.
GYXTC8Y Fig 8 Aerial Fiber Optical Cable
Model：GYXTC8Y
Name：Figure 8 self-supporting cable
Application:
☆.Adopted to Outdoor distribution.
☆.Suitable for aerial duct and buried method.
☆.Long distance and local area network communication.
Characteristics:
☆.Stainless steel or gaivanized steel self-supporting.
☆.Excellet mechanical and environmental performance
Technical parameters:
Cable Count | Outside | Weight | Minimum allowable Tensile Strength | minimum allowable Crush Load | Minimum Bending Radius | Storage | |||
(MM) | (KG) | short term | long term | short term | long term | short term | long term | (℃) | |
12 | 3.0×9.8 | 54.00 | 1000 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
