GYFTY53 uses a Fiber Reinforced Plastic (FRP) as central strength member to provides anti-electromagnetic interference property. The armored structure protects the cable from rat bite and moisture proof. The tubes (and fillers) are stranded around the strength member into a compact and circular core.
Then the cable core is covered with a thin polyethylene (PE) inner sheath, which is filled with jelly to protect it from water ingress. A layer of water-blocking material is applied around the cable core to prevent water ingress. It can be used for duct and direct buried application, suitable for frequent lightning area and anti electric field.
GYFTY53 Fiber Optical Cable
Product Name：GYFTY53
Model：Armored and Double Sheathed Outdoor Cable
Application:
☆.Adopted to Outdoor distribution.
☆.Suitable for aerial duct and buried method.
☆.Long distance and local area network communication
Characteristics:
☆.FRP strength, filler protect tube fiber, steel tape armord.
☆.Good ultra violet radiation resistant property.
☆.Double sheath .Good moisture-resistance
Technical Parameters:
Cable Count | Outer sheath | Weight | Minimum allowable Tensile | minimum allowable Crush Load | Minimum Bending | Storage | |||
(MM) | (KG) | short term | long term | short term | long term | short term | long term | (℃) | |
24 | 12.0 | 155 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
36 | 12.0 | 155 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
42 | 12.0 | 155 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
48 | 13.0 | 210 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
60 | 13.0 | 210 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
72 | 13.0 | 210 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
Optical Characteristics | ||||
Fiber type | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
A1b:62.5/125 | ||||
Single mode | G.652 (A, B, C, D) | B1.1:Conventional fiber | ||
G.653 | B2: Zero dispersion shifted | |||
G.654 | B1.2 :Cut-off wavelength shifted | |||
G.655 | B4: Main technical data for positive dispersion shifted single-mode fiber | |||
