ANSI54 Series Porcelain Stay Insulator

introduction:

The 54 Series Porcelain Stay Insulator is a highly specialized and durable component designed for use in electrical transmission and distribution systems.
In general, Porcelain insulators, play a crucial role in ensuring the safe and efficient transfer of electricity over long distances, while also protecting the supporting structures from the direct flow of current.
The 54 Series, embodies a range of advanced features and construction standards that make it an ideal choice for a wide array of applications specifically,.

Application

ANSI54 Series Porcelain Stay Insulator

The 54 Series Porcelain Stay Insulators are widely used in electrical power transmission and distribution systems, particularly in overhead lines where they provide critical support and insulation for conductors. They are ideal for use in urban, suburban, and rural areas, as well as in challenging environments such as coastal regions, industrial zones, and mountainous terrain.

Type No. :ANSI54 series

Name:Porcelain stay insulator

Color:Brown,grey gloze etc

Porcelain-Stay-Insulators-54-4_09

Porcelain-Stay-Insulators-54-4_10

Porcelain-Stay-Insulators-54-4_11

Technical Standard

ANSI CLASS		54-1	54-2	54-3	54-4
Dimensions (mm)	Height	89	108	140	171
	Hole Centers Spacing	44	57	79	67
	Hole Diameter	16	22	25	25
	Height to Hole	Max 63	Max 76	Max 103	Max 114.3
Mechanical Failing Load,kN		44	53	89	89
Power Frequency Flashover Voltage	Dry,kV	25	30	35	40
Power Frequency Flashover Voltage	Wet,kV	12	15	18	23
Net Weight,kgs		0.5	0.65	1.2	2.2
