ANSI 52 Series Porcelain Ball Socket & Clevis Tongue Insulators for Electrical Networks

Power Transmission

ANSI52 Series Porcelain Ball Socket & Clevis Tongue Insulator

introduction:

The ANSI52 Series Porcelain Ball Socket & Clevis Tongue Insulators are specialized electrical components designed for use in high-voltage power transmission systems.

These insulators feature a unique combination of ball socket and clevis tongue connections, which provide superior mechanical stability and electrical insulation.

Application

ANSI52 Series Porcelain Ball Socket & Clevis Tongue Insulator

The ANSI 52 Series Porcelain Ball Socket & Clevis Tongue Insulators are widely used in high-voltage power transmission systems, including overhead transmission lines, substations, and industrial electrical installations. They are essential components for ensuring the safe and efficient transmission of electricity over long distances.

Type No. :ANSI52 series

Name:Porcelain Ball Socket & Clevis Tongue Insulator

Color:Brown,grey gloze etc QQ图片20201201110722_08

QQ图片20201201110722_09

QQ图片20201201110722_10

Technical Standard

ANSI Class		52-1	52-2	52-3	52-4	52-5
Porcelain Sheel Diameter, D(mm)		165	190	254	254	254
Power Frequency Flashover Voltage	Dry,kV	60	65	80	80	80
Power Frequency Flashover Voltage	Wet,kV	30	35	50	50	50
Critical Impulse Flashover Voltage	Pos.,kV	100	115	125	125	125
Critical Impulse Flashover Voltage	Neg.,kV	100	115	130	130	130
Power Frequency Puncture Voltage,kV		80	90	110	110	110
Radio influence voltage data	Test Voltage to Ground,kV	7.5	7.5	10	10	10
Radio influence voltage data	Max RIV at 100 KHz,uV	50	50	50	50	50
Net Weight(kgs)		2.5	3.8	4.6	4.9	5.6
