The CGU/XGU Series Suspension Clamp is maninly used for overhead power lines or substations,and the conductor and lightning wire are hung on the insulator string or the lightning wire is hung on the tower through the connecting hardware.
It is made of Horse Iron and Aluminum Alloy.
CGU/XGU Series Suspension Clamp
Material:
Body & Keeper:CGU are made of aluminum,XGU are made of hot dip galvanzied steel.
U bolt/bolt:Hot dip galvanized steel
R Pin:Stainless steel
Technical Data:
| Type | Applicable conductor diameter(mm²） | Failure Load(KN) |
| CGU-2 | 7.0-12.4 | 40 |
| CGU-3 | 12.4-17.0 | 40 |
| CGU-4 | 19.0-21.5 | 40 |
| CGU-5 | 24.2-33.0 | 70 |
